12 Port 0.5U Cat6A STP Shielded Patch Panel 10 Inch Rack Mount 10Gigabit RJ45 Network Patch Panel

Our 12 Port Cat6A STP Shielded Patch Panel is a compact 0.5U wiring solution designed for standard 10-inch mini network racks and wall-mounted cabinets. Constructed with full metal shielded housing, this patch panel effectively blocks EMI and RFI signal interference to deliver stable 10Gigabit Ethernet transmission. It meets Cat6A Class EA 500MHz industry standards and is backward compatible with Cat5e, Cat6 network cables, ideal for small offices, home labs, surveillance rooms and smart building wiring projects.

Core Features

• 12 Shielded RJ45 Ports, Cat6A 10G Standard

  Fully complies with TIA/EIA 568-C.2 and ISO/IEC 11801 standards, supporting 500MHz high bandwidth for smooth 10Gbps data transfer. Works perfectly with IP cameras, wireless APs, VoIP phones and all PoE/PoE+/PoE++ powered devices.

• Ultra-thin 0.5U 10 Inch Rack Mount Size

  Half-unit low profile design saves valuable cabinet space. Standard 10-inch mounting holes support both rack installation and wall mounting to fit compact weak current cabinets.

• Full STP Anti-interference Metal Structure

  Integrated cold rolled steel black shell plus shielded RJ45 jacks, complete grounding accessories included to eliminate crosstalk and signal loss in complex wiring environments.

• Dual T568A & T568B Universal Wiring

  Supports 22-24AWG solid and stranded ethernet cables. Rear cable management slots keep all wiring tidy and organized for easy maintenance.

• Wide Compatibility & Durability

  Sturdy anti-rust spray metal casing, long service life, suitable for commercial, residential and monitoring network wiring systems.

Product Specifications

• Port Quantity: 12 x STP shielded RJ45 female ports

• Cable Grade: Cat6A STP Shielded

• Bandwidth: 500MHz

• Transmission Speed: Up to 10Gbps

• Rack Dimension: 10 Inch, 0.5U Height

• Housing Material: Cold rolled steel, matte black spraying

• Wiring Standard: T568A / T568B

• Applicable Wire: 22 ~ 24 AWG solid & stranded ethernet cable

• Installation: 10-inch rack mount / wall mount

• Application Scenarios: Small office cabinet, home network rack, monitoring room, smart residential wiring

Application Scenarios

This mini Cat6A patch panel is widely used for small enterprise office network layout, home server lab, security monitoring system, retail store weak current cabinet and small commercial building integrated wiring. The space-saving 0.5U design is the best choice for limited-space network cabinet projects.
