24 Port 1U Rack Mount BNC Patch Panel 75Ohm Coaxial BNC Distribution Panel for CCTV SDI Video

Our 1U 24-port BNC patch panel is a standard 19-inch rack-mount coaxial distribution panel with 75Ω impedance, specially designed for centralized wiring management of CCTV surveillance and SDI broadcast video systems. The panel body is made of thick cold-rolled steel with matte black anti-rust coating, solid structure, long service life and easy installation on standard server cabinets.

Key Features

• Standard 1U height, fits all 19-inch network/monitoring cabinets

• 24pcs high-shield BNC female connectors, stable signal transmission, low loss

• 75 Ohm characteristic impedance, match analog AHD/CVI TVI cameras & HD-SDI equipment

• Clear printed port numbers 1-24 for quick line identification and troubleshooting

• Fully shielded design to effectively block electromagnetic interference

• Support customized port count: 16 ports / 24 ports / 32 ports optional

• Simple front jump wiring, convenient for system maintenance and line adjustment

Wide Application

• Security CCTV monitoring room central wiring

• Broadcast studio, TV station SDI video signal distribution

• RF radio frequency test equipment wiring

• Traffic monitoring, factory surveillance system project

• Hospital, school, commercial building video monitoring cabinet

Product Specifications

• Height: 1U

• Standard: 19 inch rack mount

• Port quantity: 24 BNC female ports

• Impedance: 75 Ohm

• Material: Cold rolled steel plate

• Surface treatment: Black electrostatic spraying

• Connector type: BNC jack

• Operating temperature: -20℃ ~ +60℃

Our Advantages

• Direct factory supply from Ningbo, competitive FOB Ningbo price for bulk orders

• Strict raw material inspection, 100% signal test before delivery

• Flexible OEM & ODM service: custom logo, port number, panel size

• Fast production lead time, stable stock for regular models

• Professional technical support for your wiring project solution
